Monroe

Monroe RS999117 Suspension Shock Absorber

Part # RS999117
Item # 1001QTQH
$133.99
Check if this fits your vehicle
Add vehicle
Check if this fits your vehicle
Add vehicle
Dispatch within 1 business day
90 days free return

Specifications

Quantity
2
Brand
Monroe
Warranty
3-Year
Item Located
United States
Quantity
2
Color
Silver
Active or Passive Suspension
Passive
Adjustable Compression
Yes
Adjustable Damping
Yes
Adjustable Rebound
Yes
Adjustable Ride Height
No
Air Adjustable
No
Air Ride Suspension
No
Bearing Plate Included
No
Bladder Heavy Duty Crimping Rings Included
No
Bladder Included
No
Bladder Sleeve Included
No
Body Color
Silver
Body Diameter (in)
2.38
Body Diameter (mm)
60.5
Body Material
Steel
Boot Included
Yes
Coil Over Springs Included
No
Coil Spring Insulator Included
No
Compressed Length (in)
12.37
Compressed Length (mm)
314.2
Cylinder Color
Silver
Cylinder Finish
Painted
Cylinder Material
Steel
Cylinder Outside Diameter (in)
2.38
Cylinder Outside Diameter (mm)
60.5
Dust Shield Diameter (in)
2.99
Dust Shield Diameter (mm)
75.9
Dust Shield Included
Yes
Dust Shield Material
Rubber
Extended Length (in)
18.67
Extended Length (mm)
474.2
Finish
Painted
Gas Charged
Yes
Hydraulic Lockout
No
Includes Bump Stop
No
Internal Construction Type
Tri Tube
Internal Rebound Bumper
No
Lower Mount Code
L1
Lower Mount Type
Loop Bushing Mount
Mounting Hardware Included
Yes
Remote Reservoir
No
Rod Diameter (in)
0.71
Rod Diameter (mm)
18
Self-Leveling
No
Shaft Material
Nitrocarburized
Shock Absorber Bore Size (in)
1.26
Shock Absorber Bore Size (mm)
32
Shock Stroke (in)
6.3
Shock Stroke (mm)
160
Spring Included
No
Spring Isolators Included
No
Spring Seat Included
No
Strut Mount Insulator Included
No
Travel Length (in)
6.3
Travel Length (mm)
160
Type
Telescopic
Upper Mount Code
S4
Upper Mount Type
Stem Mount
Valving Type
Progressive
Show all
Note
Shock Absorber Rod End Measuring Point: Center of Loop, Shock Absorber Body End Measuring Point: Base of Stem.

Specifications

Part interchange

Part numbers listed below indicate interchangeable parts. These parts share the same size, parameter, function and compatibility. However, please note that items from different brands may have minor variations.
RS999117

Compatibility

Check if this fits your vehicle
Add vehicle
Check if this fits your vehicle
Add vehicle
This part is compatible with (21)vehicles
All
Ford
International
1966 - 1966FordBronco
1967 - 1977FordBronco
1975 - 1983FordE-100 Econoline
1975 - 1983FordE-100 Econoline Club Wagon
1975 - 1991FordE-150 Econoline
1975 - 1991FordE-150 Econoline Club Wagon
1977 - 1979FordF-150
1978 - 1979FordBronco
1980 - 1980FordBronco
1980 - 1980FordF-150
1980 - 1983FordF-100
1980 - 1986FordF-250
1981 - 1993FordBronco
1981 - 1996FordF-150
1983 - 1992FordRanger
1987 - 1996FordF-250
1994 - 1996FordBronco
1996 - 1996FordF-100 Ranger
1971 - 1971InternationalScout
1971 - 1980InternationalScout II
