Monroe

Monroe RS999047 Suspension Shock Absorber, Rear Side

Part # RS999047
Item # 1001QWTC
$134.99
Check if this fits your vehicle
Add vehicle
Check if this fits your vehicle
Add vehicle
Dispatch within 1 business day
90 days free return

Specifications

Quantity
1
Installation Position
Rear Side
Brand
Monroe
Warranty
3-Year
Item Located
United States
Quantity
1
Installation Position
Rear Side
Color
Silver
Active or Passive Suspension
Passive
Adjustable Compression
Yes
Adjustable Damping
Yes
Adjustable Rebound
Yes
Adjustable Ride Height
No
Air Adjustable
No
Air Ride Suspension
No
Bearing Plate Included
No
Bladder Heavy Duty Crimping Rings Included
No
Bladder Included
No
Bladder Sleeve Included
No
Body Color
Silver
Body Diameter (in)
2.75
Body Diameter (mm)
69.9
Body Material
Steel
Boot Included
Yes
Coil Over Springs Included
No
Coil Spring Insulator Included
No
Compressed Length (in)
18.87
Compressed Length (mm)
479.3
Cylinder Color
Silver
Cylinder Finish
Painted
Cylinder Material
Steel
Cylinder Outside Diameter (in)
2.75
Cylinder Outside Diameter (mm)
69.9
Dust Shield Diameter (in)
2.99
Dust Shield Diameter (mm)
75.9
Dust Shield Included
Yes
Dust Shield Material
Rubber
Extended Length (in)
31.21
Extended Length (mm)
792.7
Finish
Painted
Gas Charged
Yes
Hydraulic Lockout
No
Includes Bump Stop
No
Internal Construction Type
Tri Tube
Internal Rebound Bumper
No
Lower Mount Code
LS26
Mounting Hardware Included
No
Remote Reservoir
No
Rod Diameter (in)
0.71
Rod Diameter (mm)
18
Self-Leveling
No
Shaft Material
Nitrocarburized
Shock Absorber Bore Size (in)
1.26
Shock Absorber Bore Size (mm)
32
Shock Stroke (in)
12.34
Shock Stroke (mm)
313.4
Spring Included
No
Spring Isolators Included
No
Spring Seat Included
No
Strut Mount Insulator Included
No
Travel Length (in)
12.34
Travel Length (mm)
313.4
Type
Telescopic
Upper Mount Code
L1
Upper Mount Type
Loop Bushing Mount
Valving Type
Progressive
Show all
Note
Shock Absorber Rod End Measuring Point: Center of Loop, Shock Absorber Body End Measuring Point: Center of Loop.

Specifications

Part interchange

Part numbers listed below indicate interchangeable parts. These parts share the same size, parameter, function and compatibility. However, please note that items from different brands may have minor variations.
RS999047
BC3Z18125Z
BC3Z18125V
7C3Z18125MCA
BC3Z18125P
8C3Z18125MK
BC3Z18125U
9C3Z18125A
BC3Z18125AK
BC3Z18125K
BC3Z18125AM
BC3Z18125S
BC3Z18125AG
BC3Z18125N
BC3Z18125J
BC3Z18125W
BC3Z18125T
7C3Z18125LEA
8C3Z18125LK
7C3Z18125MDA
BC3Z18125Y
7C3Z18125LBA
7C3Z18125LGA
7C3Z18125LDA
7C3Z18125MBA
7C3Z18125MGA
9C3Z18125B
BC3418080LEC
7C3Z18125LCA

Compatibility

Check if this fits your vehicle
Add vehicle
Check if this fits your vehicle
Add vehicle
This part is compatible with (36)vehicles
All
Ford
2005 - 2005FordF-350 Super Duty
2005 - 2007FordF-350 Super Duty
2005 - 2007FordF-350 Super Duty
2005 - 2007FordF-350 Super Duty
2005 - 2007FordF-350 Super Duty
2005 - 2007FordF-350 Super Duty
2005 - 2010FordF-350 Super Duty
2005 - 2010FordF-350 Super Duty
2005 - 2010FordF-350 Super Duty
2005 - 2010FordF-350 Super Duty
2005 - 2010FordF-350 Super Duty
2005 - 2010FordF-350 Super Duty
2005 - 2010FordF-350 Super Duty
2005 - 2010FordF-350 Super Duty
2008 - 2009FordF-350 Super Duty
2008 - 2009FordF-350 Super Duty
2008 - 2009FordF-350 Super Duty
2008 - 2009FordF-350 Super Duty
2008 - 2010FordF-350 Super Duty
2008 - 2010FordF-350 Super Duty
