Monroe

Monroe RS55316 Suspension Shock Absorber, Rear Side

Part # RS55316
Item # 1001QX3E
$87.99
Check if this fits your vehicle
Add vehicle
Check if this fits your vehicle
Add vehicle
Dispatch within 1 business day
90 days free return

Specifications

Quantity
1
Installation Position
Rear Side
Brand
Monroe
Warranty
3-Year
Item Located
United States
Quantity
1
Installation Position
Rear Side
Color
White
Active or Passive Suspension
Passive
Adjustable Compression
No
Adjustable Damping
No
Adjustable Rebound
No
Adjustable Ride Height
No
Air Adjustable
No
Air Ride Suspension
No
Bearing Plate Included
No
Bladder Heavy Duty Crimping Rings Included
No
Bladder Included
No
Bladder Sleeve Included
No
Body Color
White
Body Diameter (in)
2.25
Body Diameter (mm)
57.2
Body Material
Steel
Boot Included
Yes
Coil Over Springs Included
No
Coil Spring Insulator Included
No
Compressed Length (in)
17.56
Compressed Length (mm)
446
Cylinder Color
White
Cylinder Finish
Painted
Cylinder Material
Steel
Cylinder Outside Diameter (in)
2.25
Cylinder Outside Diameter (mm)
57.2
Dust Shield Diameter (in)
2.99
Dust Shield Diameter (mm)
75.9
Dust Shield Included
Yes
Dust Shield Material
Rubber
Extended Length (in)
29.38
Extended Length (mm)
746.3
Finish
Painted
Gas Charged
Yes
Hydraulic Lockout
No
Includes Bump Stop
No
Internal Construction Type
Twin Tube
Internal Rebound Bumper
Yes
Lower Mount Code
LS38
Lower Mount Type
Loop Bushing and Sleeve Mount
Mounting Hardware Included
No
Remote Reservoir
No
Rod Diameter (in)
0.62
Rod Diameter (mm)
15.8
Self-Leveling
No
Shaft Material
Nitrocarburized
Shock Absorber Bore Size (in)
1.38
Shock Absorber Bore Size (mm)
35
Shock Stroke (in)
11.82
Shock Stroke (mm)
300.2
Spring Included
No
Spring Isolators Included
No
Spring Seat Included
No
Strut Mount Insulator Included
No
Travel Length (in)
11.82
Travel Length (mm)
300.2
Type
Telescopic
Upper Mount Code
LS38
Upper Mount Type
Loop Bushing and Sleeve Mount
Valving Type
Progressive
Show all
Note
Shock Absorber Rod End Measuring Point: Center of Loop, Shock Absorber Body End Measuring Point: Center of Loop.

Specifications

Part interchange

Part numbers listed below indicate interchangeable parts. These parts share the same size, parameter, function and compatibility. However, please note that items from different brands may have minor variations.
911335, 911-335 - NAPA, MONROE
252600, 252-600 - UNITY AUTOMOTIVE, UNITY
ASH24620 - MOTORCRAFT, FORD
342789 - FOCUS AUTO PARTS, FCS
GL3Z18125F, GL3Z 18125-F - FORD
ASH24619 - MOTORCRAFT
N8041 - SKYJACKER
ZX2119 - PRO COMP SUSPENSION
316580 - SACHS
2701460075 - AUTOPAR
JGT4900S - TRW
ASH25827 - MOTORCRAFT
5554373 - KYB
FL3Z18125L, FL3Z 18125-L - FORD
RS55316 - RANCHO
FL3Z18125D, FL3Z 18125-D - FORD
FL3Z18125E, FL3Z 18125-E - FORD
ASH85866 - MOTORCRAFT
ASH24621 - MOTORCRAFT
FL3Z18125F, FL3Z 18125-F - FORD
ASH85864 - MOTORCRAFT

Compatibility

Check if this fits your vehicle
Add vehicle
Check if this fits your vehicle
Add vehicle
This part is compatible with (13)vehicles
All
Ford
2015 - 2016FordF-150
2017 - 2020FordF-150
2017 - 2020FordF-150
2017 - 2020FordF-150
2017 - 2020FordF-150
2017 - 2020FordF-150
2017 - 2020FordF-150
2017 - 2020FordF-150
2017 - 2020FordF-150
2017 - 2020FordF-150
2018 - 2020FordF-150
2018 - 2020FordF-150
2018 - 2020FordF-150
