Monroe

Monroe RS55274 Suspension Shock Absorber, Rear Side

Part # RS55274
Item # 1001QSL0
$85.99
Check if this fits your vehicle
Add vehicle
Check if this fits your vehicle
Add vehicle
Dispatch within 1 business day
90 days free return

Specifications

Quantity
1
Installation Position
Rear Side
Brand
Monroe
Warranty
3-Year
Item Located
United States
Quantity
1
Installation Position
Rear Side
Color
White
Active or Passive Suspension
Passive
Adjustable Compression
No
Adjustable Damping
No
Adjustable Rebound
No
Adjustable Ride Height
No
Air Adjustable
No
Air Ride Suspension
No
Bearing Plate Included
No
Bladder Heavy Duty Crimping Rings Included
No
Bladder Included
No
Bladder Sleeve Included
No
Body Color
White
Body Diameter (in)
2.25
Body Diameter (mm)
57.2
Body Material
Steel
Boot Included
Yes
Coil Over Springs Included
No
Coil Spring Insulator Included
No
Compressed Length (in)
16.19
Compressed Length (mm)
411.2
Cylinder Color
White
Cylinder Finish
Painted
Cylinder Material
Steel
Cylinder Outside Diameter (in)
2.25
Cylinder Outside Diameter (mm)
57.2
Dust Shield Diameter (in)
2.99
Dust Shield Diameter (mm)
75.9
Dust Shield Included
Yes
Dust Shield Material
Rubber
Extended Length (in)
26.44
Extended Length (mm)
671.6
Finish
Painted
Gas Charged
Yes
Hydraulic Lockout
No
Includes Bump Stop
No
Internal Construction Type
Twin Tube
Internal Rebound Bumper
No
Lower Mount Code
LS47
Lower Mount Type
Loop Bushing and Sleeve Mount
Mounting Hardware Included
No
Remote Reservoir
No
Rod Diameter (in)
0.62
Rod Diameter (mm)
15.8
Self-Leveling
No
Shaft Material
Nitrocarburized
Shock Absorber Bore Size (in)
1.38
Shock Absorber Bore Size (mm)
35
Shock Stroke (in)
10.25
Shock Stroke (mm)
260.4
Spring Included
No
Spring Isolators Included
No
Spring Seat Included
No
Strut Mount Insulator Included
No
Travel Length (in)
10.25
Travel Length (mm)
260.4
Type
Telescopic
Upper Mount Code
LS47
Upper Mount Type
Loop Bushing and Sleeve Mount
Valving Type
Progressive
Show all
Note
Shock Absorber Rod End Measuring Point: Center of Loop, Shock Absorber Body End Measuring Point: Center of Loop.

Specifications

Part interchange

Part numbers listed below indicate interchangeable parts. These parts share the same size, parameter, function and compatibility. However, please note that items from different brands may have minor variations.
RS55274
34781
34690
520116
37164
88966851
34515
88945414
540528
RS5274
25984613
911164
550061
813005
37207
530247

Compatibility

Check if this fits your vehicle
Add vehicle
Check if this fits your vehicle
Add vehicle
This part is compatible with (48)vehicles
All
Chevrolet
Dodge
GMC
1999 - 2004ChevroletSilverado 2500
2000 - 2000ChevroletTahoe
2000 - 2000ChevroletTahoe
2000 - 2006ChevroletSuburban 1500
2000 - 2013ChevroletSuburban 2500
2001 - 2003ChevroletSilverado 1500 HD
2001 - 2006ChevroletTahoe
2001 - 2010ChevroletSilverado 2500 HD
2002 - 2006ChevroletAvalanche 1500
2005 - 2006ChevroletSilverado 1500 HD
2007 - 2007ChevroletSilverado 1500 HD Classic
2007 - 2007ChevroletSilverado 2500 HD Classic
2007 - 2013ChevroletAvalanche
2007 - 2014ChevroletSuburban 1500
2007 - 2014ChevroletTahoe
1994 - 2002DodgeRam 2500
1994 - 2002DodgeRam 3500
2002 - 2005DodgeRam 1500
2006 - 2006DodgeRam 1500
2006 - 2006DodgeRam 1500
